A hinged 70 mm window system with a potent insulation capacity and with a transmission value from only 0.8 W/m²K which has been achieved thanks to the perfect combination and design of aluminium profiles, 35 mm tubular polyamide rods, E.P.D.M tubular water tightness gaskets and a system of polyolefin foam that is fitted around the glazing space perimeter.
Possibility of straight and chamfered sashes and straight, chamfered or curved beads.
With its large glazing capacity of up to 58 mm it presents to this system some excellent acoustic and thermal features allowing the use of large glazing thicknesses and energy efficiencies
Technical Details: Cor-70-CC16
